Pallet Fork Attachment for Skid Steer Loaders

What it is used for

• Pallet handling — Loading, unloading and moving palletised goods.
• Construction material — Moving bricks, blocks, timber and pipe on site.
• Agricultural work — Handling feed bags, seed and equipment.
• Warehouse yard work — Outdoor material handling where a forklift cannot travel.
• Timber handling — Moving sawn timber and logs.
• Equipment loading — Loading and unloading plant and machinery components.

How to choose pallet forks

Forks are the single most-used attachment after the bucket. Getting the load centre and tine length right is what keeps the machine stable and the load level.

• Tine length: 1,070 mm for standard pallets, 1,220 mm and above for construction materials and long loads.
• Load capacity: rated capacity falls as load centre moves forward. Check the rating at your actual load centre, not at the tine heel.
• Tine thickness: heavier tines resist bending when handling brick, tile, and stone.
• Backrest: a tall backrest stops the load shifting back onto the operator's area.

Common questions

Can I lift with one fork only? Never. Always support the load across both tines, and keep the heaviest part close to the carriage.

How do I know the real capacity? Deduct the fork carriage weight from rated operating capacity, then apply the load-centre de-rate. We publish both figures with every quotation.

Specification considerations

Fork length and load rating must match your intended use. Longer forks increase reach but reduce rated capacity. Confirm your typical load and pallet size when ordering.

Attachment system compatibility

All our attachments use the universal quick-attach mounting plate, with standard hydraulic quick couplers — compatible with widely available attachment brands. See our attachments overview for the full range and compatibility guidance.
